Jinhua Dongda Pump Co., Ltd. is a leading manufacturer of stainless steel submersible pumps in China. The company was founded in 2001, that is, in order to meet the changing needs of various fields, to establish close and specific cooperative relations with our customers, and constantly introduce new products and new services.As water pump industry well-known brands and enterprises, the company has passed ISO9001 / ISO14001 / ISO45001 three system of quality certification, set up contains water pump manufacturing center, submersible motor manufacturing center, logistics center, can be enclosed in demand for all kinds of water to provide more suitable products. Its products are 4"-10" stainless steel deep well pump, submersible pump for DC solar well, SP all stainless steel fountain pump, DMX512 ultra-low pressure stainless steel fountain pump, and non-polluting shielded submersible motor.From the idea of a single innovative solution to the rigorous inspection, from the selection of raw materials to the production technology, we can fully meet each series of products, simple installation process, long durable cycle; Convenient, low maintenance costs, products will be excellent quality, fast after-sales service in the market.

Water flow jacket

Dongda Pumps offers a full range of stainless steel water sleeves for pumps and motors for vertical or horizontal applications.

Where the motor is not cooled enough, the use of water jacket is recommended, and the effect of its use is to extend the service life of the motor.

Water flow bushing is required in the following cases:Pump working conditions are poor, such as current imbalance, dry operation, overload, high ambient temperature, poor cooling environment, etc.

If a corrosive liquid is pumped, the corrosiveness doubles for every 10 °C increase in temperature.If there are deposits or deposits near or on the motor.

Cable

The table indicates the longest cable length in meters for different cable specifications:

from motor starter to pump, direct starting mode.

If the star/triangle starting mode is used, the current will be lower (1×0.58),

which means that the cable length can be longer than the data in the table (Lx1.73).

For example, the operating current is less than 10% of the full load current,

the length of the cable must be 10% longer than the value in the table.

The length of the cable in the table is measured when the maximum voltage drop is 1% and 3% of the rated voltage and the water temperature is up to 30 ° C.

In order to reduce the loss during operation, the cross-sectional area of the cable can be increased compared to the value indicated in the table.

Of course, this is only suitable when the size of the well hole is appropriate and the pump has a long operating time,

especially when the operating voltage is lower than the rated voltage.
